Twin Lock Distal Tibia Plate
Complex intra-articular and extra-articular fractures and osteotomies of the distal tibia
The plate is provided with a knob which sits anteriorly
Anatomically contoured; plate is twisted 20° and bent to fit the distal tibia
Four to fourteen oblong holes in the shaft
Distal Kirschner wire hole for plate placement (2.0 mm maximum diameter)
Available in stainless steel or titanium
Oblong holes in the head and six round locking holes in the head (periarticular area – distally) accept the following screws:
- – Cannulated 3.7 mm locking and cannulated 3.7 mm conical screw (for compression)
- – 3.5 mm cortex screws
- – 3.5 mm locking screws
- – 4.0 mm cancellous bone screws
- – The shaft holes accept 3.5 mm locking screws in the threaded portion and 3.5 mm cortex screws and 4.0 mm cancellous screws
