Foot and Ankle
At Sorath, we are dedicated to advancing orthopaedic care with innovative solutions for foot and ankle fractures, particularly through our New Ankle Fusion Nail. This state-of-the-art implant is designed to optimise surgical outcomes in ankle fusion procedures, providing enhanced stability and support for patients recovering from complex injuries.
Ankle Fusion Nail
An ankle fusion nail is used in ankle arthrodesis, a procedure that fuses the bones in the ankle to treat severe ankle pain and stiffness. It is a gold standard treatment for symptomatic primary, secondary and posttraumatic ankle arthritis.
Features
• Colour coded Nail for easy identification
• Pink Head indicates Right Nail
• Green Head indicates Left Nail
View More
• Double Green rings on neck indicates Proximal & Distal Screw diameter of 5.0 mm Interlocking Bone Screw
• Green & Blue rings on neck indicates Distal Screw diameter of 5.0mm Interlocking Bone Screw & Proximal Screw diameter of 4.0mm
• Diverging Screw angle allows the surgeon to target specific bone and joints
• Dynamic Compression Slot allows controlled compression
• Distal threaded screw holes help to reduce risk of screw back out while adding stability
• Rotational stability achieved with proximal static locking hole or dynamic compression slot
Download
brochure
Twin lock Anarel plate
The locking calcaneal plates address complex fractures of the calcaneus. The locking calcaneal plate is indicated for fractures and osteotomies of the calcaneus, including the following:
- Extra-calcaneal and intra-articular calcaneal fractures
- Tongue-type calcaneal fractures
- Joint depression calcaneal fractures
- Comminuted calcaneal fractures
Features
- Available in extra-small, small, large and extra-large in left and right designs
- Versatile – 15 locking holes address multiple fracture patterns
View More
- Bendable tabs provide support for the anterior process and plantar fragments
- Angled and ascending holes (indicated by arrows) buttress the sustentaculum and provide better support for the calcaneal talar articular surface
- Lateral application
- Low profile
- Malleable plate for excellent contouring
- Locking screws provide standard bi-cortical and/or uni-cortical fixation
